Used for endless joint processing of resin conveyor belts, it is highly effective in repairing, crossing, and adhering soft PVC and PU sheets.
Adhesive strength can be developed quickly by hot press bonding.
The product is resistant 57 kinds of bacteria, as approved by the IBBS (International Biodeterioration and Biodegradation Society) and 5 kinds of bacteria in line with JIS (Japanese Industrial Standards).
* ULTIGHT SUPER 780 and 780M will be discontinued. The following ULTIGHT SUPER 780A is available as a successor product.
This is a new product that combines the performance of the previous Ultite Super 780 and 780M in a single product, but with improved performance.
The main agent is compliant with the Food Sanitation Act (Positive List system) and the hardener is not covered as it is a cross-linking agent.
The product with antimicrobial functionality (see technical data for details).
Product number | Appearance | Viscosity (mPa・s/25℃) |
Open time (min) |
Mixing ratio (Main agent : Hardener) |
Features |
---|---|---|---|---|---|
N | Pale yellow liquid | 3,000~5,000 | 5~15 | 10:1 | Toluene-free, quick-drying |
NB | Black liquid | 4,000~6,000 | 5~15 | 10:1 | Toluene-free, quick-drying |
B | Black liquid | 4,000~6,000 | 10~30 | 10:1 | High final strength, excellent adhesion of wear-resistant and oil-resistant rubber |
W | White liquid | 4,000~6,000 | 10~30 | 10:1 | High final strength, excellent adhesion of wear-resistant and oil-resistant rubber |
4 | Black liquid | 4,000~6,000 | 10~20 | 10:1 | Standard type |
7 | Black liquid | 7,000~9,000 | 10~20 | 10:1 | High viscosity version of 4 |
780* | Translucent liquid | 2,000~4,000 | 5~15 | 10:0.75 | TPE conveyor belt, PVC, PU and polyester |
780M* | Translucent liquid | 2,000~4,000 | 5~15 | 10:0.75 | Excellent antibacterial and antifungal properties |
780A | Clear and colourless liquid | 2,000~4,000 | 5~15 | 10:0.75 | Plastics belts, PVC, urethane and polyester with antimicrobial functionality |
Primer P | Gray liquid | 80~150 | 30min~24hr | Primer on metal, can be bonded to 780A layer |
* 780 and 780M are discontinued soon.
* Since ULTIGHT SUPER B and ULTIGHT SUPER W use special rubber, the viscosity may change after the warranty period (6 months), but this will not affect the adhesive strength.
* ULTIGHT SUPER 780A may cause some of the antimicrobial agent to precipitate and float or settle, but this does not affect the performance of the adhesive.
Product number | Appearance |
---|---|
CA | Yellow-green or reddish brown or black-purple liquid |
CAⅡ | Light tan transparent liquid |
CA78 | Light tan transparent liquid |
Packing | For rubber | Main agent 700g and Hardener 70g |
---|---|---|
Main agent 15kg (18 liter can) and hardener 750g * In this packing form the mixing ratio is 10:0.5. | ||
For plastic | Main agent 900g and hardener 70g | |
Main agent 180g and hardener 14g | ||
Primer P | 1kg |
Before using the product, please check in advance whether it meets the purpose and conditions of use.
