ER5000 is a special thick-coatable epoxy resin which has excellent chemical resistance and is a repair lining material that adheres even to wet surfaces. By adding ebonite powder at the time of use, it is possible to make lining materials from high viscosity to putty.
| Product number | Appearance | Viscosity (mPas/25℃) |
Pot life (min/25℃) |
Setting time (hr/25℃) |
Standard mixing ratio | Applications etc | ||
|---|---|---|---|---|---|---|---|---|
| Main agent | Hardener | Main agent | Hardener | |||||
| ER5000 | Light yellow liquid | Tan transparent liquid | 700～1,100 | 2,000～4,000 | 60 | 24 | 3:2 | Lining material |
| Ebonite powder | Black brown powder | ― | 1 : 1 (Recommendation) | |||||
50-60 Shore D (Base agent: Hardener = 3:2)
65-85 Shore D (Base agent + Hardener: Ebonite powder = 1:1)
| Packing | Main agent 3kg and hardener 2kg |
|---|---|
| Main agent 3kg, hardener 2kg and ebonite powder 5kg |
Before using the product, please check in advance whether it meets the purpose and conditions of use.
